产品名称： LW8116-41RMJ
产品简介：
适用场所：办公室门 财务室门 家庭房门 药品库门 政府机要室门 总经理办公室门 智能小区
产品材质：锌合金材料，标准密度6.75g/cm3
可选颜色：青古铜 红古铜 金色 银色 镀真金
门厚要求：适合安装在38mm-1000mm厚的门上
开门方式：密码，卡片或机械钥匙
驱动方式：电机双向驱动
密码容量：50个
卡片容量：200张
工作温度：-20℃— +55℃
工作湿度：10%-90%.
抗静电：>15000V
工作电压：直流6V（4节碱性AA电池）
静态功耗：小于40uA
动态功耗：小于200mA
电池寿命：正常连续开启10000次左右
欠压指示：当工作电压低于4.8V左右时，开门会有弱电提示，此时还能开门200次左右
机械锁体：天地杆防盗锁体/五锁舌三联动锁体，防插斜舌设计
电路板芯片： 荷兰Philips 的 Mifare One 原装进口芯片
适用卡型：Mafire 1卡
产品尺寸：350*90mm
Product features
Application places: office door, accounting office door, family door, drug depository door, government confidential room door, general manager's office door, intelligent village
Product material: zinc alloy material, standard density 6.75 g/cm 3
Optional color: green bronze， red bronze，gold ,silver ,gilt
Door thick requirement: suitable for installation in 38 mm - 1000 mm thick door
Open the door way: password, card or mechanical keys
Driving mode: motor two-way drive
Password capacity: 50
Card capacity: 200 copies
Working temperature: - 20 ℃ - + 55 ℃
Work humidity: 10% -90%.
Antistatic: > 15000 v
Working voltage: dc 6 V (section 4 basic AA battery)
Static power: less than 40 uA
Dynamic power consumption: less than 200 mA
Battery life: normal continuous open 10000 times or so
Undervoltage instructions: when work voltage is lower than 4.8 V around, open the door there will be weak current hint, now still can open the door 200 times or so Mechanical lock body: heaven and earth bar anti-theft lock body/five lock tongue three linkage lock body, prevent plug oblique tongue design
Circuit chip: Dutch Philips Mifare One of original installation import chip
Applicable card type: Mafire 1 card
Product size:350 * 90mm
